Integrated Servostepmotor

Linear unit CTJ145
stroke 3500mm
long carriage
number of carriages: 1
Drive pulley left with keyway
no connection plate

Linear unit MTJ 110
stroke 1200 mm
1 long carriage
left with keyway
without protection cover

Electric cylinder PNCE 40
Ball screw 16x05
Stroke 350mm

Electric cylinder PNCE 63
Ball Screw 25x10
Stroke 1200mm
Piston rod: Male thread

Electric cylinder PNCE 32
Ball Screw 12x05
Stroke 600mm
Piston rod: Male thread

Linear unit CTJ110
stroke 900mm
long carriage
number of carriages: 1
Drive pulley right with keyway
with connection plate

Linear unit MTV80
Stroke: 700mm
Ball screw: 20x05
Tolerance class: ISO7
Without keyway
Number of carriages: 1
Number of screw supports: 0

Servomotor with harmonic gearbox

Bracket for gas springs with Ø8mm hinge eye
including retaining clip
Stainless version AISI304
Max load 1200N

Bevel gear set spiral toothed module 3.5 number of teeth 25/25 i=1:1 material steel 16MnCr5 teeth hardened

Bansbach Lockable Gas spring
EL1 = 165mm

Bansbach Lockable Gas spring
250N
EL1 = 165mm

Bansbach Gasspring
Standard version with normal push-out speed and normal end damping
Size: 14/28 with stroke 200mm
EL1 length: 700mm
push out force: 2000N
with hinge eyes on both sides

Servoactuator slag 100mm met 200W servomotor met rem
Artikel: xxx

Bansbach gasspring

Timing belt pulley MAED-FIX® with clamp hub profile T5 18 teeth bore 6H7 for belt width 10mm ALK23T5/18-2

Motor side drive for Electric Cylinder PNCE40
Reduction ratio 1

Electric Cylinder PNCE 32
Ball Screw 12x10
Stroke 250mm
IP65

inline DC actuator iCON35
Integrated controller Multiple actuator - Direction control - Override input (MDO)
Shielded cable without connector
IP69 Harsh environment stainless steel
Brackets: Stainless steel
Tube: Stainless steel
Piston ring: Stainless steel harsh environment
