Can-stack stepper linear actuator

Stepper motor controller
12-72 VDC with 8IOA and optional CANopen/DeviceNet and encoder (Default 9 Amp.)
Up to 3 Amp
Hardware version 1. (default)
5xM12. 2x4pF:EtherNetIP 17pF:8xDIO/AI+RS422+RS485 5p:Motor
No magnetic chip.
PCB, Motor connector 4 pin JST
IP42 housing. Motor: M12 type A female max RMS motor current 3.4 Amp/phase. Peak 5 Amp

Can-stack stepper linear actuator

Concens iCON35 actuator
Stroke: 50 mm
Gear ratio: 5:1 (Maximum load 120 N – Nominal speed 33 mm/s)
24 VDC
Cable length: 1 m shielded cable – Molex connector
Integrated controller: MDO – Multi-actuator
Standard steel – IP66
Black tube and black piston ring

Integrated Servo Motor
320W - 0.8Nm
RMS
4000RPM
12-48VDC
High Torque, Ethernet Ready

Connection plate CTV110 L 90 MTV80 Z KPL

Integrated Servo Motor
320W - 0.8Nm
RMS
4000RPM
12-48VDC
High Torque, Ethernet Ready
incl. HW STO M8 4pin

Integrated Servo Motor
320W - 0.8Nm
RMS
4000RPM
12-48VDC
High Torque, Ethernet Ready

Ball flange bearing UFL 005 bore 25mm with eccentric ring material zinc die cast

Clamping fixture CTV110/145 l=142 M6 B

Timing belt pulley MAED-FIX® with clamp hub profile AT5 25 teeth bore 14H7 for belt width 16mm ALK34AT5/25-2

Bansbach Easylift Traction spring

Bansbach Easylift Gas Spring
Standard push out version
normal speed and end-damping
with hinge eyes on both sides: Ø6.2mm
EL1: 367mm
F: 150N

Concens CON35 actuator
Stroke: 500 mm
Gear ratio: 14:1 (Maximum load 400 N – Nominal speed 16 mm/s)
24 VDC
Cable length: 3 m shielded cable – without connector
With Hall sensors
Standard steel – IP68
Black tube and black H.E. piston ring

Concens CON35 actuator
Stroke: 750 mm
Gear ratio: 14:1 (Maximum load 400 N – Nominal speed 16 mm/s)
24 VDC
Cable length: 3 m shielded cable – without connector
With Hall sensors
Stainless steel (AISI316) – IP68
Stainless steel tube and stainless steel piston ring

Driver for BLDC motor
DIP switches for configuration
Speed selection - status LED
Protection rate IP20

Integrated Servostepmotor

Concens iCON35 actuator
Stroke: 50 mm
Gear ratio: 71:1 (Maximum load 2200 N – Nominal speed 3 mm/s)
24 VDC
Cable length: 3 m shielded cable – without connector
Integrated controller: MDO – Multi-actuator
Stainless steel (AISI316) – IP68
Stainless steel tube and stainless steel piston ring

Side drive for Electric cylinder PNCE32
Reduction ratio: 1

SGN32 MSD mounting att. accessory
Material: aluminium
