MD200 Drive - NC Series
Three-phase 380 to 480 Vac -15% to +10%
Rater input currect (A): 4.5
Drive output: 0.75kW

Bevel gear made of stainless steel 1.4305
module 2,5
22 teeth
i=1:1
*** toothing geometry according to our machine data ***
*** Axial angle 90° ***
*** When placing an order, we require the installation dimensions and tooth width***.

universal joint shaft
both sides bore 12H7 min.
length 140 mm max. length 160 mm
stainless steel 1.4301
outer diameter 25 mm

Bansbach Easylift Gas Spring
Build in length: EL1: 1266mm
With hinge eyes on both sides
Push-out force F1: 5150N

MSD MG 60 T1
Motor Side drive for
Linear Unit MGTB/MGBS 60
suitable for motor NEMA 23 (size 56x56 - shaft Ø6,35mm)

Drummotor TM113.1 x 260 0.25 0.21 stainless steel cylindrical
including sprockets (included separately)

Bansbach Easylift Lockable Gas Spring
B-type Spring locking
Stainless steel gas spring
Short release system / slow
Hinge eye cilinder side
Threaded end piston side M10x1
With valve
Build-in-length EL1: 501 mm
Push-out force F1: 300N

Inline DC Actuator CON35
With hall sensors
Black cable, no connector
Alu brackets

Inline DC Actuator CON50
With hall sensors
Black cable, no connector
Alu brackets

Inline DC Actuator iCON35
Integrated controller - MDO
Black shielded cable, with Molex Minifit Jr. connector
Alu brackets

Inline DC Actuator iCON50
Integrated controller - MDO
Black shielded cable, with Molex Minifit Jr. connector
Alu brackets

Linear unit MTJ 40
1 carriage
Both sides with keyway
without protection cover

Linear unit MTJ 40
1 carriage
Right with keyway
without protection cover

Synchronization shaft: OSL
Linear unit MTJ 40 to linear unit MTJ 40
Size 19/24
Distance LM: 1292mm
Drive shaft: F10C
Driven shaft: F10C

VK MTJ40 40 GESM14
Motor coupling part for MTJ40

Bansbach Easylift Gas spring 250N

Integrated Servostepmotor

Linear unit CTJ145
stroke 3500mm
long carriage
number of carriages: 1
Drive pulley left with keyway
no connection plate

Linear unit MTJ 110
stroke 1200 mm
1 long carriage
left with keyway
without protection cover

Electric cylinder PNCE 40
Ball screw 16x05
Stroke 350mm
