Linear unit MRJ 65
Carriage: long
Number of carriages: 1
Drive pulley: left with keyway
Inox protection cover

Linear unit MTV65
Ball screw: 16x05
Tolerance class: ISO7
Keyway: yes
Carriage: 1
Number of screw supports: 2

MSD CTV110 MTV65 T1 1 60 x 60
Motor type: flange 60 x 60 mm
Mounting screws are included

Bansbach Easylift Gas spring
Heat setup version (sealings)
with Valve in the Cylinder threaded end
F1 Push-out force: 700N
EL1 Build-in length: 375mm
With Elbowjoint D3 on both sides

Metal Clad Braking Resistor
800W - 5% - 47Ω

Electric cylinder MCE45 with Integrated Stepper Motor MIS231S1

1. Con50
2. Stroke Length: 100mm
3. Low Noise: Standard
4. Gear Ratio: 24/1 - 3100N - 12mm/s
5. Voltage & Certifications: 24VDC
6. Pitch & Nut: 3mm
7. Cable Length: 9m
8. Cable Type & Connector: Black cable, Molex Minifit Connector
9. Without hall sensors
10. Steel & IP Class: Std. steel, IP66
11. Brackets: Aluminum
12. Tube Color: Black, RAL9005, shine 25
13. Piston Ring Color: Black, standard

MD630 AC Drive

Steppingmotor of the AZ-Series;
Round shaft

MAEDLER stainless steel deep groove ball bearing single row inner Ø 10mm outer Ø 30mm width 9mm with blue NBR seals on both sides

iCon 50 linear actuator
Integrated controller MDO for multiple actuators
with molex minifit connector
iCon version SBS (Single setup - Bus-based - status control)
alu brackets wit clevis
Black tube and piston ring
RAL9005, shine 25
Harsh Environment IP68 protection

iCon 50 linear actuator
Integrated controller MDO for multiple actuators
with molex minifit connector
iCon version SBS (Single setup - Bus-based - status control)
Stainless steel brackets with clevis
Stainless steel tube and piston ring
Harsh Environment IP68 protection

MD630 AC Drive

Helical bevel gear
Input size: 50/70 M5
Input shaft: d14mm
Max output torque: 88Nm

Steppingmotor-Gearhead Combination of the AZ-Series;

in-line linear actuator with DC motor
CON35
Black cable, Molex Minifit connector
without hall sensors
Std steel, harsh environment
Brackets: AISI316

In-line linear actuator with DC motor
CON60 without Hall sensor
Alu brackets without Clevis
with molex connector

DC motor
Nom current (A) : 3.5
Starting torque/current (Nm / A) 40/354
shaft type E35 12mm

in-line linear actuator with DC motor
CON35
Black cable, Molex Minifit connector
without hall sensors
Std steel, harsh environment
Brackets: AISI316

Con 50 linear actuator
With Hall sensors
with molex minifit connector
alu brackets with clevis
Black tube and piston ring
RAL9005, shine 25
Harsh Environment IP68 protection
