AC Servo Motor (medium inertia type)
Un=230V
In=1.3A
26Bit multiturn encoder
max. Speed : 7000 rpm

Parallel Shaft Gearhead;

GL20 expansion module
8 x sink (NPN) digital inputs and 8 x sink (NPN) transistor outputs module (Response time 100 μs.)

Bansbach Easylift Gas Spring
Stainless steel AISI 316L
EL1 length: 228mm
Normal speed and normal end-damping

SV680 Servo Drive
In=2.8A, Imax=10.1A
5x DI, 1x DO, 2x AI, 1x AO
STO, IP20
24V DC backup power supply

SV680 Servo Drive
In=5.5A, Imax=16.9A
5x DI, 1x DO, 2x AI, 1x AO
STO, IP20
24V DC backup power supply

GL20 Power supply expansion

Multi-axes stepper drives
+ up to 4 stepping motors (max. 1.4A/phase per motor)
+ mixed 2-phase and 5 phase stepping motors
+ encoder feedback
+ EM brake outputs
+ power supply for sensors

Parallel Driver for 4 actuators or motors
12/24Vdc
4x10A

Linear Motor Coil Assembly

U shaped Magnet Way
For LM-PB series linearmotor

Linear Motor Coil Assembly

U shaped Magnet Way
For LM-PD series linearmotor

U shaped Magnet Way
For LM-PD series linearmotor

Integrated Servostepmotor
Ø6.35x20 mm D-cut
Shaft: IP42
Motor: IP42

VK CTV145 MTV80 60 x 60 GESM14
-Dummy-
Motor adapter for CTV145 and MTV80
Fastening screws are included

Motor type: Motor flange 60 x 60 mm
Coupling: GESM14

VK PNCE40 EKL10 0 S 57x57
Motor adapter for PNCE 40
Motor type: flange 57 x 57 mm
Coupling EKL10
Mounting screws are included

Hybrid linear actuator, captive type
Linear travel per step(mm):0.0015

AZ Series Key Shaft Stepper Motor with Absolute Mechanical Encoder
Connector type

AZ mini driver connection cables
Cable Output in shaft direction
Connector type
(suitable for Mini driver or Multi-axis driver slim version)
