Synchronised driver for 2 brushed DC motors
24VDC - 2×10 A

Linear unit MTJ 65
Carriage: short
Number of carriages: 1
Drive pulley: right with keyway
Without protection cover

Linear unit MTJ 65
Carriage: short
Number of carriages: 1
Drive pulley: both sides with keyway
Without protection cover

Integrated Servostepmotor

+ Output Shaft (mm) : 6.35 x 20 ; D-shape

Concens CON60 actuator
Stroke: 750 mm
Gear ratio: 66:1 (Maximum load 5000 N – Nominal speed 8 mm/s)
24 VDC
Cable length: 5 m shielded cable – without connector
With Hall sensors
Standard steel – IP66
Black tube and black piston ring
Warning: Maximum load limited due to stroke > 400 mm

Cable Connection Cable for Motor

Inline DC actuator iCON35
Integrated controller - Single/Direction/Basic IO (SDB)
Black shielded cable with Molex Minifit Jr. Connector
Alu brackets

VK MTJ65 AMP 60PE010 GESM19/24 SAM1465
Motor Adapter for MTJ/MRJ / MTJZ 65

Timing belt pulley AT5 material aluminium 36 teeth for belt width 16mm 27 AT5/36-2 + adapted with 2 x Flange for timing belt pulley thickness 1mm Ø 63 x 57 x 48mm stainless steel

Inline DC actuator iCON35
Integrated controller - Single/Bus/Status (SBS)
Black shielded cable with Molex Minifit Jr. Connector
Alu brackets

BRL100
no gear

Concens Inline DC actuator iCON35
Integrated controller - Single/Position/Position (SPP)
Black shielded cable with Molex Minifit Jr. connector
Std. steel – IP66
Alu brackets

MSD PNCE80 T2 1 IP65CR
Side drive for
Electric cylinder PNCE 80
Reduction ratio: 1
IP65CR

Alu Push Button for lockable gasspring
Suitable for short release
With coil spring

in-line linear actuator with DC motor
Type : iCON35 SPP 12 VDC
Harsh environment version
10m black cable without connector
stroke 100mm
SPP= built-in controller for analog positioning
front bracket AISI316 with clevis
rearbracket: AISI316 w/o clevis

Bansbach Gas spring
stroke 15mm
Pushout Force F1: 110N

IR-R7H (Hollow wrist) 6- AXIS Robot
Vertical multi-articulated
Controller type IRCB501 Series included

Teach pendant

Encoder card

Safety card
