MSD PNCE32 T0 1,5 IP65CR
Side drive for Electric cylinder PNCE32
Reduction ratio: 1,5

MecVel Linear Actuator with DC motor

Bansbach Gas Spring

A5 = Piston rod connection: Clevis fork DIN 71752G 8x16 without spring pin
A3 = Cylinder connection: Angle joint DIN 71802CS 13xM8
4 = Normal extension speed, normal end cushioning
2 = Series with Ø6 mm piston rod and Ø15 mm cylinder
100 = Stroke in mm
368 = EL1 = Extended installation length
760N = Extension force in N
EL2 = 306 mm

Hybrid linear actuator, non-captive type

Mecvel Linear actuator with DC Motor
stroke 250mm
24V DC motor
Rod end

SV680 Servo Drive
In=26A, Imax=65A
5x DI, 1x DO, 2x AI, 1x AO
STO, IP20

Mecvel Linear actuator with DC Motor
stroke 250mm
24V DC motor
Rod end A1

Planetary gearbox

Cable Connection Cable for Encoder

Bansbach Easylift Gas spring
Stainless steel
F1 Force: 300N

Bansbach Easylift Gas spring
Build-in length EL1: 160mm
Push-out Force F1: 400N

Flexible Extension Cable for Motor – Motor side

Flexible Extension Cable for Motor – Motor side

Flexible Extension Cable for Encoder

Flexible Extension Cable for Encoder

Bansbach Easylift Gas spring
EL1Build in length: 186mm
F1 push-out force: 30N
push out : slow, increased end damping
with elbowjoints on both sides

Flexible Connection Cable for motor

Bansbach gas spring
360N

Timing belt pulley HTD 5M material steel 16 teeth for belt width 9mm Including modification: Bore 8H7

Electric cylinder PNCE 50
Ball screw: 2005
Stroke: 50mm
Version: S
Piston rod thread: Male
