in-line linear actuator with DC motor
CON35
Black cable, without
without hall sensors
Std steel
Brackets: alu

in-line linear actuator with DC motor
CON35
Black cable, without connector
without hall sensors
Harsh Environment version
AISI 316 Tube and piston
Brackets: AISI316

Stainless Steel Worm Gearmotor
Size: N50
250W, i=50, output speed 28rpm 53Nm
Hollow output shaft diameter 25mm
With output flange
Double seal for IP69K, life lubricated bearings on output
Food-grade oil

In-line DC actuator iCON35
with integrated controller SDB (simple I-O)
Std Steel version with alu brackets

BLS Series Brushless DC Motor
Pinion Shaft

BLS Series Brushless DC Motor Driver

Connection Cable

In-line linear actuator iCon50
Integrated controller MDO(Multiple-direction-override)
Black screened cable, Molex Minifit Jr. Connector
Low noise version
Alu Brackets

Bansbach Easylift Lockable gas spring
B-Model (spring type)
Short release with valve
Normal speed.
Build-in length EL1: 470mm
Push-out force F1: 240N

Bansbach Easylift HB Damper
Adjustable
Damping in both directions
Without free travel(slip)
Pushout Force 50N
EL1 build in lengh: 322mm
M8 thread on cylinder side
S3 Hinge eye on piston rod Ø8.1

Bansbach Easylift Lockable gas spring
B-Model (spring type)
Short release with valve
Normal speed.
Build-in length EL1: 382mm
Push-out force F1: 240N

Bowden Wire for splitter (release head)
From splitter to release head
length1500mm

Planetary Gearbox

CON50 In-line actuator
with Molex Minifit Connector
Brackets: Aluminum
Powder Coated std steel version

CON50 in-line actuator
with Molex Minifit Connector
Brackets: Stainless steel
AISI316 body, piston and pistonring
Harsh Environment version

CON35 in-line actuator
With Molex Minifit Connector
Brackets: Stainless steel
AISI316 body, piston and pistonring
Harsh Environment version

2 Phase Stepping Motor of the PKP-Series;
Frame Size 28 mm
Type SH Geared With Encoder
Maximum Holding Torque 0.4 N·m
Speed Range 0–83 r/min
Backlash 90 arcmin (1.5°)

In-line linear actuator iCon50
Integrated controller MDO(Multiple-direction-override)
Black screened cable, Molex Minifit Jr. Connector
Low noise version
Alu Brackets with clevis

Module MD630 AC Drive

CON35 in-line actuator
With Molex Minifit Connector
Brackets: alu
Std steel body, Alu piston
