Product Series: con50
Stroke Length: 400
Low Noise: Standard
Gear Ratio:24/1
Voltage & Certifications: 24VDC
Pitch & Nut: 3mm
Cable Length: 5m
Cable Type & Connector: Black cable, Molex Minifit Connector
Hall Sensors: With hall sensors
Steel & IP Class: Std. steel, IP66
Brackets: Aluminum
Tube Color: Black, RAL9005, shine 25
Piston Ring Color: Black

CON50 stroke 500mm
Ratio 17/1 - 2200N - 17mm/s
24V DC - With Hall Sensors
5m cable with Molex Connector
low-noise version
std steel IP66
alu brackets with clevis
Black tube and piston ring
RAL9005, shine 25

Electric cylinder PNCE 40
Ball Screw 16x16
Stroke 350 mm
Version: FI
Piston rod: Female thread

Electric cylinder PNCE 32
Ball Screw 12x10
Stroke 350 mm
Version: FI

Electric cylinder PNCE 40
Ball Screw 16x16
Stroke 350 mm
Version: FI

Timing belt pulley T5 material aluminium 20 teeth for belt width 16mm 27 T5/20-2 Including modification Bore 12H7. Keyway 4P9. Alignment for gearing elements without reference to teeth

Electric cylinder PNCE 40
Ball Screw 16x16
Stroke 400 mm
Version: FI

Adjustable clamping lever type K lever length 45 mm shaft length 20 mm external thread M6 x 18mm

Linear unit MGBS 45
Ball screw 10x3
Stroke 800mm
Stepper motor with encoder (size 42mm Nema17)
Mounting option: with MSD facing right
CD connectors facing down
with drive (closed loop) - Ethernet based communication
Without cables

Linear unit MGBS 45
Ball screw 10x03
Stroke 200mm

Electric cylinder PNCE 32
Ball Screw 12x05
Stroke 200mm
Piston rod: Male thread

Cable encoder STCF E A12 03
Suitable for motor STMN 42, STMN 56
Angled connector M12, 8pin
Suitable for cable chain use
Shielded cable

Cable motor STCF M A12 03
Suitable for motor STMN 42, STMN 56
Angled connector M12, 5pin
Suitable for cable chain use

Cable power STCF P 02
Suitable for pulse-direction, Ethercat & Ethernet drives
Length: 2m

Cable signal STCF S EN 02
Suitable for Ethernet drives
Length: 2m

Electric cylinder PNCE 40
Ball Screw 16x10
Stroke 50 mm
Version: FI

Worm gear unit KES 30 version A center distance 30mm ratio 17:1 output hollow shaft 14mm

Planetary Gearbox

High Torque Stepper Motor

Stepper motor type STMN 42 L E
High torque, NEMA 17 stepper motor with M12 type connectors
Plug & Drive solution with Unimotion drives
Mass moment of inertia: 0,082 kg cm^2
Encoder resolution: 2000 ppr
Without brake
RoHS 2011/65/EU, 2015/863/EU approved
