Kardan verbinding
Omschrijving
Universal joints and universal shafts are versatile components for transferring rotary motion and transmitting torque from the driving to the driven unit. If two shafts set at a certain angle are connected using a single universal joint and one shaft turns with constant velocity, the other shaft will move irregularly.
This non-uniformity – also called gimbal error – means that angle of rotation of the second shaft slightly lags behind or leads the movement off the first shaft, with kind of sinus-shaped variations. The greater the operating angle, the greater the non-uniformity in motion of the second shaft.
Thus single universal joints are only used in applications where non-uniformity of rotation is acceptable. This non-uniformity can be compensated by either using two single universal joints in sequence - thus forming a universal shaft - or by using a double universal joint.
When properly installed, the second universal joint
can compensate the non-uniform rotation of the first universal
joint, that is under the following preconditions, as described in
DIN 808:
Enkele producten uit deze categorie
| Product | Omschrijving | Afbeelding |
|---|---|---|
|
63199237
Maedler |
Precision single universal joint WER DIN 808 simple, bore 18H7 stainless steel 1.4301 total length 108mm outer diameter 37mm |
|
|
63199237N
Maedler |
Precision single universal joint WER DIN808 bore 18H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
63199240
Maedler |
Precision single universal joint WER DIN 808 simple, bore 20H7 stainless steel 1.4301 total length 108mm outer diameter 40mm |
|
|
63199240N
Maedler |
Precision single universal joint WER DIN808 bore 20H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
63199247
Maedler |
Precision single universal joint WER DIN 808 simple, bore 22H7 stainless steel 1.4301 total length 127mm outer diameter 47mm |
|
|
63199247N
Maedler |
Precision single universal joint WER DIN808 bore 22H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
63199250
Maedler |
Precision single universal joint WER DIN 808 simple, bore 25H7 stainless steel 1.4301 total length 140mm outer diameter 50mm |
|
|
63199250N
Maedler |
Precision single universal joint WER DIN808 bore 25H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
63199257
Maedler |
Precision single universal joint WER DIN 808 simple, bore 30H7 stainless steel 1.4301 total length 178mm outer diameter 58mm |
|
|
63199257N
Maedler |
Precision single universal joint WER DIN808 bore 30H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
63199620
Maedler |
Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 10H7 |
|
|
63199620N
Maedler |
Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 10H7 with keyway DIN 6885-1 on both sides |
|
|
63199626
Maedler |
Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 14H7 |
|
|
63199626N
Maedler |
Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 14H7 with keyway DIN 6885-1 on both sides |
|
|
63199632
Maedler |
Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 16H7 |
|
|
Made to specifications, article group 600 |
|
|
|
Made to specifications, article group 600 |
|
|
| Products | ||
|---|---|---|
|
|
63199237
Maedler Precision single universal joint WER DIN 808 simple, bore 18H7 stainless steel 1.4301 total length 108mm outer diameter 37mm |
|
|
|
63199237N
Maedler Precision single universal joint WER DIN808 bore 18H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
|
63199240
Maedler Precision single universal joint WER DIN 808 simple, bore 20H7 stainless steel 1.4301 total length 108mm outer diameter 40mm |
|
|
|
63199240N
Maedler Precision single universal joint WER DIN808 bore 20H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
|
63199247
Maedler Precision single universal joint WER DIN 808 simple, bore 22H7 stainless steel 1.4301 total length 127mm outer diameter 47mm |
|
|
|
63199247N
Maedler Precision single universal joint WER DIN808 bore 22H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
|
63199250
Maedler Precision single universal joint WER DIN 808 simple, bore 25H7 stainless steel 1.4301 total length 140mm outer diameter 50mm |
|
|
|
63199250N
Maedler Precision single universal joint WER DIN808 bore 25H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
|
63199257
Maedler Precision single universal joint WER DIN 808 simple, bore 30H7 stainless steel 1.4301 total length 178mm outer diameter 58mm |
|
|
|
63199257N
Maedler Precision single universal joint WER DIN808 bore 30H7 with keyway DIN 6885-1 tolerance JS9 on both sides stainless steel 1.4301 |
|
|
|
63199620
Maedler Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 10H7 |
|
|
|
63199620N
Maedler Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 10H7 with keyway DIN 6885-1 on both sides |
|
|
|
63199626
Maedler Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 14H7 |
|
|
|
63199626N
Maedler Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 14H7 with keyway DIN 6885-1 on both sides |
|
|
|
63199632
Maedler Precision double universal joint WDNR stainless steel 1.4301 with needle bearing made of bearing steel bore 16H7 |
|
|
|
Made to specifications, article group 600 |
|
|
|
Made to specifications, article group 600 |
|
