Electric Cylinder type MSCE 32
Ball screw Φ8x2
Stepper with encoder and brake (NEMA 17)
With MSD facing left
Connectors facing left
Without drive

Integrated Servo Motor
2700rpm @ 48VDC - 1350rpm @ 24VDC 0.48Nm/1.59Nm
IP67 without brake
Incremental magnetic 8192 CPR + Absolut multiturn encoder 19bit
Color: White
Ø6.35x20.5 mm D-shape

Bansbach Gas spring size 10/22
M2 hinge eyes on both sides
Normal speed with normal end damping
Extension Force F1: 750N

steel rubber bush PHO-V inner diameter 08mm outer diameter 16mm length of inner bush 17mm length of outer bush 15mm vulcanized version

VK CTJ110 60 x 60 GESM14
Motor type: flange 60x60 mm
Coupling: GESM14
- mounting screws included

Linear unit MGBS 60
Ball screw 12x10
Stroke 600mm
without motor

Driver of the BLE2-Series;
for motor with EM brake

Linear unit MGTB 60
Stroke: 2000mm
without motor

Electric cylinder PNCE 40
Ball Screw; 16x05
Stroke 900mm
Piston rod: Male thread
IP65CR

Bansbach Lockable Gas spring typ 'B'
Size 10/28 - stroke 60mm
EL1: 276mm
Pushout Force F1: 650N
With Hinge eyes A1 on cylinder side
With threaded end K0 on piston side

Bansbach Gas Spring stainless steel Quick Ship version
Stroke 200mm Push out Force 700N Thread on both sides M8

Bansbach Easylift
Lockable gas spring P-type
With clevis connection on Cylinder side
Stroke: 200mm
F1 Force: 300N

Anti Backlash nut for screw diameter 10mm / lead 2,54mm

DC motor
Nom current (A) : 7
Starting torque/current (Nm / A) 135 / 49
shaft type E37 14mm

Linear stepper motor
with linear guide

Cable set for AZ-series
Connects AZM46, AZM48, AZM66, AZM69 motors to AZ-mini driver or AZ Multi-axis Slim type driver
Standard cable version
Cable length: 1 m

Cable set for AZ-series
Connects AZM46, AZM48, AZM66, AZM69 motors to AZ-mini driver or AZ Multi-axis Slim type driver
Standard cable version
Cable length: 3 m

Electric cylinder PNCE 50
Ball Screw; 20x20
Stroke 600mm
Piston rod: Female thread

Bansbach Easy Lift Gas spring
size 14/28
with special configurated end damping
With A1 end pieces on both sides (dia.8.2mm)

in-line linear actuator with DC motor
