LZ 63/80 mounting attachment accessory

ZKCE63 mounting att. accessory

Electric cylinder PNCE 63
Ball Screw 25x10
Stroke 350mm
Piston rod: Male thread

Linear unit CTV110
Ball Screw: 16x10
Stroke 300mm
Tolerance class: ISO7
with Keyway
1 Long carriage
with connection plate
with Inox protection cover

Electric Cylinder MCE45
Ball screw 10x03
stroke: 300mm
without motor

Servoactuator slag 150mm met 200W servomotor met rem
Artikel: M3063892

Servoactuator slag 200mm met 200W servomotor met rem
Artikel: M3063893

Servoactuator slag 300mm met 200W servomotor met rem
Artikel: M3063894

MSD PNCE63 T1 1 S
Side drive for PNCE63
Reduction ratio: 1
Motor type: divide circle of the attachment screws on motor max. 140mm
Mounting screws included

Linear unit MTV65
Ball screw: 16x05
Tolerance class: ISO7
With keyway
Stroke: 70mm
1 carriage

VK CTV110 MTV65 60 x 60 GESM14
Motor adapter VK CTV 110
Motor type: flange 60 x 60mm
- mounting screws included

Electric Cylinder MCE45
Without guiding unit
Ball screw 10x10
Stroke 200mm
Male thread

Spur gear stainless steel 1.4305 with hub module 3 28 teeth tooth width 30mm outside diameter 90mm

Electric Cylinder MCE32
Ball screw 08x02
Stroke: 50mm
Piston rod: male thread
Stepper motor Nema17 with encoder and brake
Mounting option: with motor adapter VK
Motor connectors facing up
Without drive

Electric cylinder PNCE 32
Ball Screw: 12x05
Stroke: 50mm
IP65
Piston rod: male thread

Planetary gearbox

Worm gear unit KES 30 version A center distance 30mm ratio 25:1 output hollow shaft 14mm

Flanged bush similar to DIN 1850-3 V sintered bronze bore 32mm outer diameter 40mm flange diameter 48mm length 20mm

SV660 Servo Drive
In=7.6A, Imax=17A,
STO, IP20

Connecting part
Clevise with clip bolt
GAK/EBL = 40MM/M10/Ø10MM
