Description
Mounting Adapter for Linear Actuator
Frame Size 42 mm
Lead 12 mm
Stroke 300 mm
Repetitive Positioning Accuracy ±0.05 mm
Transportable Mass Horizontal 10 kg
Transportable Mass Vertical 5 kg
Drive Screw Type Lead Screw
Screw Diameter Φ8 mm
Permissible Thrust, Permissible Speed
100 N (0–80 mm/s) · 80 mm/s
50 N (0–180 mm/s) · 180 mm/s
Self-Locking Force 0 N
Materials Screw Shaft: Stainless Steel
Nut: PPS
Applicable Product 2-Phase·Stepping Motors Frame Size 42 mm
LA4212C30
https://actintime.callista.be/shop/la4212c30-242060
https://actintime.callista.be/web/image/product.template/242060/image_1920?unique=8a0176c
Mounting Adapter for Linear Actuator
Frame Size 42 mm
Lead 12 mm
Stroke 300 mm
Repetitive Positioning Accuracy ±0.05 mm
Transportable Mass Horizontal 10 kg
Transportable Mass Vertical 5 kg
Drive Screw Type Lead Screw
Screw Diameter Φ8 mm
Permissible Thrust, Permissible Speed
100 N (0–80 mm/s) · 80 mm/s
50 N (0–180 mm/s) · 180 mm/s
Self-Locking Force 0 N
Materials Screw Shaft: Stainless Steel
Nut: PPS
Applicable Product 2-Phase·Stepping Motors Frame Size 42 mm
