AZ Series

Description

De AZ Series van Oriental motor zijn zogenaamde Servosteppers. Deze motoren hebben een hoge effictiëntie en lage vibratie.

Flensmaat van 20 mm tot 85 mm
Mechanische absolute encoder
AC of DC input types
Stappenmotoren met opgebouwde reductiekast voor betere inertie-matching
Optioneel met elektromagnetische rem
AZD-C driver nodig voor de aansturing van AC-motoren
AZD-K driver nodig voor de aansturing van DC-motoren

Het AC type is als volgt samen te stellen:

Het DC type is als volgt samen te stellen:

Some products from this category

Product	Description	PICTURE
AZM66ACH Orientalmotor	Stepping Motor of the AZ‑Series (Connector Type) AC-input Frame Size: 60 mm Holding Torque (Nm): 1.2 Encoder: Absolute
AZM66A0KH Orientalmotor	Steppingmotor of the AZ-Series; Dimension (mm): 60 x 60 Encoder: Absolute Protection class: IP65
AZM66A0CH Orientalmotor	AZ Series Stepper Motor Connector type AC Input Dimension (mm): 60 x 60 Encoder: Absolute Electromagnetic Brake: No
AZM48AKH Orientalmotor	Stepping motor of the AZ-Series Frame size: 42 mm Holding torque: 0.72 Nm Encoder: Absolute Connection type: Connector Input type: DC Dimension (mm): 42 x 42 Encoder: Absolute Electromagnetic Brake: No
AZM48ACH Orientalmotor	Stepping motor of the AZ-Series Frame size: 42 mm Holding torque: 0.77 Nm Encoder: Absolute Connection type: Connector Input type: AC
AZM48A0KH Orientalmotor	Stepping motor of the AZ-Series Frame size: 42 mm Holding torque: 0.72 Nm Encoder: Absolute Connection type: Connector Input type: DC Electromagnetic Brake: No Encoder: Absolute Dimension (mm): 42 x 42
AZM48A0CH Orientalmotor	Stepping motor of the AZ-Series Frame size: 42 mm Holding torque: 0.77 Nm Encoder: Absolute Connection type: Connector Input type: AC Dimension (mm): 60 x 60 Holding Torque (Nm): 0.77 Encoder: Absolute
AZM46MKH-PS36 Orientalmotor	Steppingmotor of the AZ-Series; Dimension: 60x60 Gear ratio: 36 Electromagnetic brake: Yes
AZM46MKH-PS25 Orientalmotor	Steppingmotor of the AZ-Series; Dimension: 60x60 Gear ratio: 25 Electromagnetic brake: Yes
AZM46MKH-PS10 Orientalmotor	Steppingmotor of the AZ-Series; Dimension: 60x60 Gear ratio: 25 Electromagnetic brake: Yes
AZM46MKH-FC30DA Orientalmotor	AZ SERIES DC TYPE, ALPHA STEP
AZM46MKH Orientalmotor	Stepping motor of the AZ-Series Frame size: 42 mm Holding torque: 0.3 Nm Encoder: Absolute Electromagnetic brake: Yes Connection type: Connector Input type: DC
AZM46MCH Orientalmotor	Stepping motor of the AZ-Series Frame size: 42 mm Holding torque: 0.3 Nm Encoder: Absolute Electromagnetic brake: Yes Connection type: Connector Input type: AC
AZM46AKH-TS7.2 Orientalmotor	Stepping motor gearhead combination of the AZ-Series Frame size: 42 mm Gearhead type: TS Geared Type (spur gear) Gear ratio: 7.2:1 Max. holding torque: 1.2 Nm Encoder: Absolute Connection type: Connector Input type: DC Gear: ratio 7.2 Encoder: Absolute Electromagnetic Brake: No
AZM46AKH-PS50 Orientalmotor	Stepping motor gearhead combination of the AZ-Series Frame size: 42 mm Gearhead type: PS Geared Type (planetary) Gear ratio: 50:1 Max. holding torque: 3 Nm Encoder: Absolute Connection type: Connector Input type: DC Gear: ratio 50 Dimension (mm): 42 x 42 Max. Speed (rpm): 60 Holding Torque (Nm): 3.0 Encoder: Absolute Protection class: IP66
AZM46AKH-HS100 Orientalmotor	Stepping motor gearhead combination of the AZ-Series Frame size: 42 mm Gearhead type: Harmonic Geared Type (harmonic drive) Gear ratio: 100:1 Max. holding torque: 5 Nm Encoder: Absolute Connection type: Connector Input type: DC
AZM46ACH-PS50 Orientalmotor	Stepping motor gearhead combination of the AZ-Series Frame size: 42 mm Gearhead type: PS Geared Type (planetary) Gear ratio: 50:1 Max. holding torque: 3 Nm Encoder: Absolute Connection type: Connector Input type: AC Gear: ratio 50 Electromagnetic Brake: No Encoder: Absolute
AZM46ACH	Stepping motor of the AZ-Series Frame size: 42 mm Holding torque: 0.3 Nm Encoder: Absolute Connection type: Connector Input type: AC
AZM46A0CH	Stepping motor of the AZ-Series Frame size: 42 mm Holding torque: 0.3 Nm Encoder: Absolute Connection type: Connector Input type: AC Dimension (mm): 42 x 42 Encoder: Absolute Electromagnetic Brake: No
AZM24AK-HS50 Orientalmotor	AZ series DC type, Alpha Step Harmonic geared Single shaft Gear: ratio 50 Electromagnetic Brake: No
