Neoprene timing belt HTD 3M width 9mm Lw 177mm 59 teeth

Timing belt pulley HTD 3M material aluminium 12 teeth for belt width 9mm

Spider (coupling insert) backlash-free 92 Shore A yellow size 28 outside diameter 65mm

Clamp hub for elastic coupling RNKC short backlash-free size 28 borehole 25mm outer diameter 65mm length 38.5mm

Sprocket KRR with hub 06 B-1 3/8x7/32" 20 teeth material stainless steel 1.4301 (AISI 304)

Sprocket KRR with hub 06 B-1 3/8x7/32" 14 teeth material stainless steel 1.4301 (AISI 304)

Locking assembly BAR bore 40mm

Ready-to-install flange nut Tr.20 x 4 single-start right material red brass

Bush EP22 bore 12mm outer diameter 14mm length 20mm colour: white

Linear slide with ball screw

Elastic coupling RNH
with half shell clamps
backlash-free
size 14
boreholes 11mm
outer diameter 30mm
overall length 35mm
insert 98° shore red
- Including modification: Bore 12H9. Bore 14H9.

MAEDLER stainless steel deep groove ball bearing single row inner Ø 15mm outer Ø 35mm width 11mm with blue NBR seals on both sides

MAEDLER stainless steel deep groove ball bearing single row inner Ø 35mm outer Ø 62mm width 14mm with blue NBR seals on both sides

MAEDLER stainless steel deep groove ball bearing single row inner Ø 12mm outer Ø 21mm width 5mm with blue NBR seals on both sides alternative marking 6801

Linear unit CTV 110
with double linear guide
stroke 250mm
max travel speed 0.35m/s
max acceleration 20m/s²
ISO7 = +/- 0.02mm precision

MD800 Dual Drive
Output current : 1.9A (ND)

iCON50 stroke 350mm
Ratio 24/1 Nom.speed: 12mm/s
Nom.Force: 3100N
Max Stat.load: 16,8kN
with integrated controller
iCon MDO (multiple)
with 3m black cable (molex connector)
Std.steel version IP66
with alu brackets with Ball Bearing.
Black motor tube and piston ring.

MD800 Single Drive Unit 200V
Pn=1.5kW
With STO function
IP40

Electric cylinder PNCE 40
Ball Screw 16x10
Stroke 350 mm
Version: FI

PLC with
Motion axis : 4 (pulse control axis)
Encoder axis : 4 channel encoder axis
Pulse output : 4 x 200KHz
Extension modules : 8
Communication Port : 1 x RS232 + 1 x RS485
Protocols : Serial free protocol, Modbus RTU/ASC
Program storage : 128K step
Data storage : 1Mbyte（128KB non-volatile）
Instruction execution time : 20K step / 2ms
Dimensions(WxHxD:mm) : 24x100x83
Other interface Type-C
Built in IO : 8 input / 8 output
Programming language LD、SFC、FB/FC(support encryption functionality), ST(under development)
Power input DC24V

Neoprene timing belt HTD 3M width 9mm Lw 177mm 59 teeth

Timing belt pulley HTD 3M material aluminium 12 teeth for belt width 9mm

Spider (coupling insert) backlash-free 92 Shore A yellow size 28 outside diameter 65mm

Clamp hub for elastic coupling RNKC short backlash-free size 28 borehole 25mm outer diameter 65mm length 38.5mm

Sprocket KRR with hub 06 B-1 3/8x7/32" 20 teeth material stainless steel 1.4301 (AISI 304)

Sprocket KRR with hub 06 B-1 3/8x7/32" 14 teeth material stainless steel 1.4301 (AISI 304)

Locking assembly BAR bore 40mm

Ready-to-install flange nut Tr.20 x 4 single-start right material red brass

Bush EP22 bore 12mm outer diameter 14mm length 20mm colour: white

Linear slide with ball screw

Elastic coupling RNH
with half shell clamps
backlash-free
size 14
boreholes 11mm
outer diameter 30mm
overall length 35mm
insert 98° shore red
- Including modification: Bore 12H9. Bore 14H9.

MAEDLER stainless steel deep groove ball bearing single row inner Ø 15mm outer Ø 35mm width 11mm with blue NBR seals on both sides

MAEDLER stainless steel deep groove ball bearing single row inner Ø 35mm outer Ø 62mm width 14mm with blue NBR seals on both sides

MAEDLER stainless steel deep groove ball bearing single row inner Ø 12mm outer Ø 21mm width 5mm with blue NBR seals on both sides alternative marking 6801

Linear unit CTV 110
with double linear guide
stroke 250mm
max travel speed 0.35m/s
max acceleration 20m/s²
ISO7 = +/- 0.02mm precision

MD800 Dual Drive
Output current : 1.9A (ND)

iCON50 stroke 350mm
Ratio 24/1 Nom.speed: 12mm/s
Nom.Force: 3100N
Max Stat.load: 16,8kN
with integrated controller
iCon MDO (multiple)
with 3m black cable (molex connector)
Std.steel version IP66
with alu brackets with Ball Bearing.
Black motor tube and piston ring.

MD800 Single Drive Unit 200V
Pn=1.5kW
With STO function
IP40

Electric cylinder PNCE 40
Ball Screw 16x10
Stroke 350 mm
Version: FI

PLC with
Motion axis : 4 (pulse control axis)
Encoder axis : 4 channel encoder axis
Pulse output : 4 x 200KHz
Extension modules : 8
Communication Port : 1 x RS232 + 1 x RS485
Protocols : Serial free protocol, Modbus RTU/ASC
Program storage : 128K step
Data storage : 1Mbyte（128KB non-volatile）
Instruction execution time : 20K step / 2ms
Dimensions(WxHxD:mm) : 24x100x83
Other interface Type-C
Built in IO : 8 input / 8 output
Programming language LD、SFC、FB/FC(support encryption functionality), ST(under development)
Power input DC24V
