Inline DC actuator CON60
Without hall sensors
Black cable, Molex Minifit Jr. Connector
Std. steel, Harsh Environment (HE)
Alu Brackets with spherical bearings

Inline DC actuator CON60
Without hall sensors
Black cable, Molex Minifit Jr. Connector
Std. steel, Harsh Environment (HE)
Alu Brackets with spherical bearings

Stainless Steel Motor Size 63
0.18kW - 4P
Mounting IMB14
3phase 230/400V 50HZ
Cooling TENV (Not Ventilated)
Without coating
Efficiency IE4
PREMIUM IP69K

Stainless Steel Motor Size 71
0.25kW - 4P
Mounting IMB14
3phase 230/400V 50HZ
Cooling TENV (Not Ventilated)
Without coating
Efficiency IE4
PREMIUM IP69K

Stainless Steel Motor Size 71
0.37kW - 4P
Mounting IMB14
3phase 230/400V 50HZ
Cooling TENV (Not Ventilated)
Without coating
Efficiency IE4
PREMIUM IP69K

Aluminum Motor Size 63
0.18kW - 4P
Mounting IMB14
3phase 230/400V 50HZ
Cooling TENV (Not Ventilated)
Standard coating
Efficiency IE4
PREMIUM IP69K

Aluminum Motor Size 71
0.25kW - 4P
Mounting IMB14
3phase 230/400V 50HZ
Cooling TENV (Not Ventilated)
Standard coating
Efficiency IE4
PREMIUM IP69K

Aluminum Motor Size 71
0.37kW - 4P
Mounting IMB14
3phase 230/400V 50HZ
Cooling TENV (Not Ventilated)
Standard coating
Efficiency IE4
PREMIUM IP69K

Bansbach Easylift Gas spring
Stainless Steel 316L
Stroke: 324mm
Length EL2: 890mm

Integrated AC Servomotor
400W - 1.27Nm
115 - 230VAC
3000rpm - isolated ground,
built in Powerlink

Gas Spring / 5000N

Integrated Stepper Motor
Holding Torque: 3 Nm
Max. 190.49 W
Radial Connector
12-72 VDC
2xRS485, 8xIOA (ePLC)/RS422 (Encoder Input)

Inline DC actuator iCON35
Integrated controller MDO (Multiple actuator - Direction control - Override input)
Std steel, Harsh Environment (HE)
Black Shielded cable with Molex Minifit Jr. Connector
Alu brackets

Inline DC actuator iCON35
Integrated controller MDO (Multiple actuator - Direction control - Override input)
Std steel, Harsh Environment (HE)
Black Shielded cable with Molex Minifit Jr. Connector
Alu brackets

Inline DC actuator iCON50
Integrated controller MDO (Multiple actuator - Direction control - Override input)
Std steel, Harsh Environment (HE)
Black Shielded cable with Molex Minifit Jr. Connector
Alu brackets

Inline DC actuator iCON50
Integrated controller MDO (Multiple actuator - Direction control - Override input)
Std steel, Harsh Environment (HE)
Black Shielded cable with Molex Minifit Jr. Connector
Alu brackets

Smooth surface aluminum worm gearboxes
Type B - Size: D45
Mounting BRZ (Reaction arm)

+ Twin viton seals - Shield IP69K
+ Food safe lubricant mobil oil
+ Life lubricated bearings on output

Connection Cable for motor

Cable Connection Cable for Encoder

Connection Cable For Electromagnetic Brake
