Bansbach Easylift Gas Spring

Bansbach Easylift Traction gas spring
100N

MSD CTV145 MTV80 T1 1 60 x 60
Motor type: flange 60 x 60 mm
Mounting screws are included

319-dc gearmotor
24Vdc
45 rpm at 9Nm

Bush ISO 2795 (DIN 1850-3) shape J sintered bronze borehole 25mm outer diameter 30mm length 40mm *** old product code 62335910 ***

Electric cylinder PNCE 40
Ball screw 16x05
Stroke 80mm

SGS M12 x 1,25 piston rod accessory

Connecting Bracket for Gas Spring with Ø8mm hinge eye
Stainless version AISI304
Max load 3000N

Electric cylinder PNCE 63
Ball Screw 25x10
Stroke 120mm
Piston rod: Male thread

SGL 63 mounting attachment accessory

Connecting part A5
Clevis without clip bolt
EBL=32mm / M10 / Ø8H9

Bansbach Gas spring
Stroke 300mm
800N

VK CTJ200 NP025 GESM28/38 SAM1376
Gearbox adapter for CTJ200 and gearbox NP025 and
Coupling GESM28/38 F22C F24X
With mounting screws

Bansbach Lock spring 250N
Stroke: 434mm
EL1: 1005mm

Bansbach Lock spring 300N
Stroke: 434mm
EL1: 1005mm

Bansbach Easylift Damper
Adj. /000N

Lockable gas spring
up to length 300mm / 1000N
CeramPro finished piston
Powder coated Housing
Release system not included
incl. selection based on 2D drawing and theoretical specification or refence nr
spare part item or prototype

Stainless Steel Worm Gearmotor
Size: N50
250W, i=60, output speed 23,33rpm 62Nm
Mounting position: B3

- Food safe lubricant
- Twin viton seals IP69K
- Life lubricated output bearings

VK CTJ110 AZM66ACH-PS25 GESM14 SAM3703
Motor adapter for CTJ 110 and motor AZM66ACH-PS25 and coupling
GESM14 F12C F14x
- mounting screws are included

MSD CTV 145 T1 1 AZM66MCH_V SAM3704
Motor side drive - MSD for CTV 145 / MTV 80 and motor AZM66MCH_V
Type: T1
Ratio i:=1
