CON35 in-line actuator
Stainless steel version
no hall sensors without connector

1. Con50
2. Stroke Length: 300 mm
3. Low Noise: Standard
4. Gear Ratio: 14/1 ; Force: 1750N ; nom.Speed: 20mm/s
5. Voltage & Certifications: 24VDC
6. Pitch & Nut: 3mm
7. Cable Length: 5m
8. Cable Type & Connector: Shielded Black cable, no connector
9. Hall Sensors/Integrated Controller (icon): Without hall sensors
10. Steel & IP Class: Std. steel, IP66
11. Brackets: Aluminum with spherical bearings
12. Tube Color: Black, RAL9005, shine 25
13. Piston Ring Color: Black, standard

Intel Celeron 1.6 GHz
DDR 4 GB, SSD 128 GB,
dot matrix digital display module 128 x 64 dots, 4 keys
EtherCAT bus master station, LAN x4, USB2.0 x2, USB3.0 x2, RS485 x1, RS232 x1, 3 DIs, 2 DOs

Linear unit MGTB 60
without motor

Double sprocket ZRENG for 2 single roller chains 12 B-1 21 teeth material steel teeth hardened

SV680 Servo Drive
In=1.6A, Imax=5.8A
5x DI, 1x DO, 2x AI, 1x AO
STO, IP20
24V DC backup power supply

AC Servo Motor (medium inertia type)
Un=230V
In=1.3A
26Bit multiturn encoder
max. Speed : 7000 rpm

Parallel Shaft Gearhead;

GL20 expansion module
8 x sink (NPN) digital inputs and 8 x sink (NPN) transistor outputs module (Response time 100 μs.)

Bansbach Easylift Gas Spring
Stainless steel AISI 316L
EL1 length: 228mm
Normal speed and normal end-damping

SV680 Servo Drive
In=2.8A, Imax=10.1A
5x DI, 1x DO, 2x AI, 1x AO
STO, IP20
24V DC backup power supply

SV680 Servo Drive
In=5.5A, Imax=16.9A
5x DI, 1x DO, 2x AI, 1x AO
STO, IP20
24V DC backup power supply

GL20 Power supply expansion

Multi-axes stepper drives
+ up to 4 stepping motors (max. 1.4A/phase per motor)
+ mixed 2-phase and 5 phase stepping motors
+ encoder feedback
+ EM brake outputs
+ power supply for sensors

Parallel Driver for 4 actuators or motors
12/24Vdc
4x10A

Linear Motor Coil Assembly

U shaped Magnet Way
For LM-PB series linearmotor

Linear Motor Coil Assembly

U shaped Magnet Way
For LM-PD series linearmotor

U shaped Magnet Way
For LM-PD series linearmotor
